Functions
More precise joints.
Oval shape, larger glued area, more stability. The DOMINO system unites the precision of a round dowel with the flexibility of a traditional flat dowel – the perfect solution for panel joints. The system consists of the DF 500 dowel jointer, DOMINOs in different sizes and a wide range of accessories for special applications. The result: extremely strong, invisible joints. And DOMINO can do much more: rack joints, frame joints, drawer joints, etc.
- Varied use with dowel sizes from 4 x 20 mm to 10 x 50 mm
- Patented routing principle unique to hand-held machines for accurate work with no kickbacks
- Stops that are quick and easy to adjust, for accurate results
- Ergonomic shape for ease of operation in any position
- Rotation-proof joint with DOMINO dowels providing maximum stability
- System accessories compatible with both DOMINO jointers
Usage
Main applications
- Furniture manufacture
- Shopfitting/Interior fitting
- Window construction
- Exhibition stand construction
- For panel joins
- For frame and rack joints
Technical Data
Technical data
Power consumption
420 W
Idle engine speed
25 500 min⁻¹
Depth stop for routing depth
12, 15, 20, 25, 28 mm
Max. routing depth
28.00 mm
DOMINO slot cutter dia.
4, 5, 6, 8, 10 mm
Routing height adjustment
5 – 30 mm
Mitre routing
0 – 90 °
Dust extraction connection diameter
27 mm
Cable length
4.00 m
Product weight
3.20 kg
Drive type
Mains
